60
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_meas_gpow_desc.fm
Gated Power Measurement Description
• For the falling trace, data points 4894 through 5264 (the last 371) are displayed with each data point
occupying one display pixel.
• For the Full/Zoomed trace spanning the entire 1277 uS measurement period, averaging over groups of data
points will be performed to include all 5,264 data points using the display’s 371 pixels.
• For the Full/Zoomed trace that zooms in on the area highlighted by the vertical bar, the correlation between
data points and pixels is as follows:
— For the first or last zoomed segment the correlation between data points and display pixels will be
identical to the Rise/Fall traces, with the first or last 371 data points displayed on 371 pixels.
— For all of the middle 12 zoomed segments, the time period (when compared with rise/fall graphs) will be
compressed in time. Each data point will span a time period four times longer than the rise/fall data
points. This will result in about one fourth the display resolution when compared with the rise/fall
traces.
Table 4. Graticule Line Labeling for all Zoomed Traces
Zoom
Position
DSP Output
Range (points)
Count of
Data
Points
µ s
Graticule
Line 0
µ s
Graticule
Line 2
µ s
Graticule
Line 4
µ s
Graticule
Line 6
µ s
Graticule
Line 8
µ s
Graticule
Line 10
0 0-370 371 -15 -10 -5 0 5 10
1 371 to 747 377 10 31 51 71 92 112
2 748 to 1124 377 112 133 153 174 194 214
3 1125 to 1501 377 215 235 255 276 296 317
4 1502 to 1878 377 317 337 358 378 399 419
5 1879 to 2255 377 419 440 460 480 501 521
6 2256 to 2632 377 521 542 562 583 603 623
7 2633 to 3008 376 624 644 664 685 705 726
8 3009 to 3385 377 726 746 767 787 808 828
9 3386 to 3762 377 828 849 869 889 910 930
10 3763 to 4139 377 930 951 971 992 1012 1032
11 4140 to 4516 377 1033 1053 1073 1094 1114 1135
12 4517 to 4893 377 1135 1155 1176 1196 1216 1237
13 4894 to 5264 371 1237 1242 1247 1252 1257 1262
