Chapter 4 INTERFACE SETTINGS
99
CDC Msg = 2 (Set State Adj)
《Setting item when CDC Msg = 2 (Set State Adj) is selected》
Select the setting method of the destination device of message.
0 Auto Send message to the adjacent devices of
VG main unit.
* If there are several adjacent devices, the
message is sent to the device that has
smaller Logical Address.
(1) Set Mode (0/1)
1 Manual Message is sent to the device set in the
below “Dev Physical Addr”.
(2) Dev Physical Addr Set Physical Address of the destination device of message.
(This is available only when Set Mode=1(Manual))
Setting of the HEC Set State
0 Deactivate HEC
(3) HEC Set State (0/1)
1 Activate HEC
《Criteria of result judgment》
When either of below 2 conditions is fulfilled, the result is PASS.
Condition 1 Set Mode = Auto
・ <CDC_HEC_ReportState> is responded by the adjacent devices of VG main unit.
Condition 2 Set Mode = Manual
・ <CDC_HEC_ReportState> is responded from the device designated by Dev Physical Addr.
Note : when setting by Set Mode=Manual, if the setting value of Dev Physical Addr and Physical address of VG
main unit are same (message destination = VG main unit), the result is FAIL.
Or, if the device set by Dev Physical Addr does not exist, the result is FAIL.
CDC Msg = 3 (Set State)
《Setting item》
(1) Dev Physical Addr1 Set Physical Address of the first Terminating Device.
(2) Dev Physical Addr2 Set Physical Address of the second Terminating Device.
Setting of the HEC Set State
0 Deactivate HEC
(3) HEC Set State (0/1)
1 Activate HEC
《Criteria of result judgment》
If the below condition is fulfilled, the test result becomes PASS.
・ DUT (the device designated by Target Logical Addr) is included in the channel designated by the
Dev Physical Addr1 and the Dev Physical Addr2.
and
There is a response of <CDC_HEC_ReportState> from the DUT>.
