ASTRO VG Series User Manual

188
a) Concerning the all program fixed setting
The “program setting” for the following setting items can be ignored and output can be performed with the entire
program fixed according to the “device config setting”. For example, this is used to set an entire sample
program to HPD mode OFF, or to change the output video bit length but leave other settings unchanged, etc.
Parameters which can be set to program fixed
Item Remarks
Width Refer to “4.1.5 Setting the bit length (gray scale) for pattern drawing.”
Link Set Mode
HPD Mode
InfoFrame
SSC
See below.
Follow the procedure below to set Link Set Mode and HPD Mode.
(1)
Select Configuration using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select DP using
or
INC
DEC
, and
then select
SET
.
Select the items using or
INC
DEC
,
and then press
SET
.
(3)
<Inputting the parameters>
Select the parameters using
or
INC
DEC
, and then press
SET
.
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For further details on the parameters, refer to <Program
fixed setting parameters>.
