ASTRO VG Series User Manual

332
<3D pattern details>
[0] Color Bar V-1
The same vertical color bars are output at the left and right. “LEFT” and “RIGHT” are displayed for left and right,
respectively.
LEFT RIGHT
[1] Color Bar V-2
The vertical color bar shown in the figures below are output at the left and right.
LEFT RIGHT LR combination
[2] Vertical Bar
Vertical bars each consisting of one dot are output. The pattern is the same for the left and right.
[3] Checker DOT
Checkerboard dot by dot patterns are output. The colors for the pattern on the left are reversed from the colors in
the pattern on the right.
LEFT RIGHT
} L side
} R side
} L side
} R side
} L side
} R side
1dot
