Version 6.6 109 Mediant 2000
User's Manual 11. Network
5. Configure the interface according to the table below.
6. Click the Apply button; the interface is added to the table and the Done button
appears.
7. Click Done to validate the interface. If the interface is not valid (e.g., if it overlaps with
another interface in the table or if it does not adhere to the other rules as summarized
in 'Multiple Interface Table Configuration Summary and Guidelines' on page 111), a
warning message is displayed.
8. Save the changes to flash memory and reset the device (see 'Saving Configuration' on
page 396).
To view configured network interfaces that are currently active, click the IP Interface Status
Table button. For more information, see Viewing Active IP Interfaces on page 448.
Multiple Interface Table Parameters Description
Parameter Description
Table parameters
Index
[InterfaceTable_Index
]
Table index row of the interface.
The range is 0 to 15.
Web: Application Type
EMS: Application
Types
[InterfaceTable_Appli
cationTypes]
Defines the applications allowed on the interface.
 [0] OAMP = Operations, Administration, Maintenance and Provisioning
(OAMP) applications (e.g., Web, Telnet, SSH, and SNMP).
 [1] Media = Media (i.e., RTP streams of voice).
 [2] Control = Call Control applications (e.g., SIP).
 [3] OAMP + Media = OAMP and Media applications.
 [4] OAMP + Control = OAMP and Call Control applications.
 [5] Media + Control = Media and Call Control applications.
 [6] OAMP + Media + Control = All application types are allowed on the
interface.
Note: For valid configuration, see Multiple Interface Table Configuration
Rules on page 111.
Web/EMS: IP Address
[InterfaceTable_IPAd
dress]
Defines the IPv4 IP address in dotted-decimal notation.
Note: For valid configuration, see Multiple Interface Table Configuration
Rules on page 111.
Web/EMS: Prefix
Length
[InterfaceTable_Prefi
xLength]
Defines the prefix length of the related IP address. This is a Classless
Inter-Domain Routing (CIDR)-style representation of a dotted-decimal
subnet notation. The CIDR-
style representation uses a suffix indicating the
number of bits which are set in the dotted-decimal format. For example,
192.168.0.0/16 is synonymous with 192.168.0.0 and subnet 255.255.0.0.
This CIDR lists the number of ‘1’ bits in the subnet mask (i.e., replaces the
standard dotted-decimal representation of the subnet mask for IPv4
interfaces). For example, a subnet mask of 255.0.0.0 is represented by a
prefix length of 8 (i.e., 11111111 00000000 00000000 00000000) and a
subnet mask of 255.255.255.252 is represented by a prefix length of 30
(i.e., 11111111 11111111 11111111 11111100).
The prefix length is a Classless Inter-Domain Routing (CIDR) style
presentation of a dotted-decimal subnet notation. The CIDR-style
presentation is the latest method for interpretation of IP addresses.
Specifically, instead of using eight-bit address blocks, it uses the variable-
length subnet masking technique to allow allocation on arbitrary-length
prefixes.
