Version 6.6 291 Mediant 2000
User's Manual 23. Manipulation
Parameter Description
message, then the value of this parameter is compared to the P-
Asserted-Identity URI host name (instead of the From header).
Web: Destination Host
Prefix
[DestHost]
Defines the Request-URI host name prefix of the incoming SIP
INVITE message.
Notes:
 This parameter is applicable only to the number manipulation
tables for IP-to-Tel calls.
 The asterisk (*) wildcard can be used to denote any prefix.
Web: Source Trunk Group
[SrcTrunkGroupID]
Defines the source Trunk Group ID for Tel-to-IP calls. To denote all
Trunk Groups, leave this field empty.
Notes:
 The value -1 indicates that this field is ignored in the rule.
 This parameter is applicable only to the number manipulation
tables for Tel-to-IP calls.
 For IP-to-IP call routing, this parameter is not required (i.e., leave
the field empty).
Web: Source IP Group
[SrcIPGroupID]
Defines the IP Group from where the IP call originated. Typically, the
IP Group of an incoming INVITE is determined or classified using the
Inbound IP Routing Table. If not used (i.e., any IP Group), leave the
field empty.
Notes:
 The value -1 indicates that this field is ignored.
 This parameter is applicable only to the number manipulation
tables for Tel-to-IP calls.
 If this Source IP Group has a Serving IP Group, then all calls from
this Source IP Group are sent to the Serving IP Group. In this
scenario, this table is used only if the PreferRouteTable parameter
is set to 1.
Web: Destination IP Group
[DestIPGroupID]
Defines the IP Group to where the call is sent.
Notes:
 The value -1 indicates that this field is ignored.
 This parameter is
applicable only to the Destination Phone Number
Manipulation Table for Tel -> IP Calls.
Operation (Action)
Web: Stripped Digits From
Left
EMS: Number Of Stripped
Digits
[RemoveFromLeft]
Defines the number of digits to remove from the left of the telephone
number prefix. For example, if you enter 3 and the phone number is
5551234, the new phone number is 1234.
Web: Stripped Digits From
Right
EMS: Number Of Stripped
Digits
[RemoveFromRight]
Defines the number of digits to remove from the right of the telephone
number prefix. For example, if you enter 3 and the phone number is
5551234, the new phone number is 5551.
Web: Prefix to Add
EMS: Prefix/Suffix To Add
[Prefix2Add]
Defines the number or string that you want added to the front of the
telephone number. For example, if you enter 9 and the phone number
is 1234, the new number is 91234.
Web: Suffix to Add Defines the number or string that you want added to the end of the
