Version 6.6 661 Mediant 2000
User's Manual 45. Configuration Parameters Reference
Parameter Description

[6] By Source Phone Number
 [7] Trunk Cyclic Ascending
 [8] Trunk & Channel Cyclic Ascending
 [11] Dest Number + Ascending
Notes:
 For a detailed description of the parameter's options, see
'Configuring Trunk Group Settings' on page 281.
 Channel select mode per Trunk Group can be configured in the
Trunk Group Settings (see 'Configuring Trunk Group Settings' on
page 281).
Web: Default Destination
Number
[DefaultNumber]
Defines the default destination phone number, which is used if the
received message doesn't contain a called party number and no
phone number is configured in the Trunk Group Table' (see
Configuring the Trunk Group Table on page 279). This parameter is
used as a starting number for the list of channels comprising all the
device's Trunk Groups.
The default is 1000.
Web: Source IP Address
Input
[SourceIPAddressInput]
Determines which IP address the device uses to determine the
source of incoming INVITE messages for IP-to-Tel routing.
 [-1] = (Default) Auto Decision - if the IP-to-IP feature is enabled,
this parameter is automatically set to Layer 3 Source IP. If the IP-
to-IP feature is disabled, this parameter is automatically set to
SIP Contact Header (1).
 [0] SIP Contact Header = The IP address in the Contact header
of the incoming INVITE message is used.
 [1] Layer 3 Source IP = The actual IP address (Layer 3) from
where the SIP packet was received is used.
Web: Use Source Number
As Display Name
EMS: Display Name
[UseSourceNumberAsDi
splayName]
Determines the use of Tel Source Number and Display Name for
Tel-to-IP calls.
 [0] No = (Default) If a Tel Display Name is received, the Tel
Source Number is used as the IP Source Number and the Tel
Display Name is used as the IP Display Name. If no Display
Name is received from the Tel side, the IP Display Name remains
empty.
 [1] Yes = If a Tel Display Name is received, the Tel Source
Number is used as the IP Source Number and the Tel Display
Name is used as the IP Display Name. If no Display Name is
received from the Tel side, the Tel Source Number is used as the
IP Source Number and also as the IP Display Name.
 [2] Overwrite = The Tel Source Number is used as the IP Source
Number and also as the IP Display Name (even if the received
Tel Display Name is not empty).
 [3] Original = Similar to option [2], except that the operation is
done before regular calling number manipulation.
Web/EMS: Use Display
Name as Source Number
[UseDisplayNameAsSour
ceNumber]
Determines the use of Source Number and Display Name for IP-to-
Tel calls.
 [0] No = (Default) If IP Display Name is received, the IP Source
Number is used as the Tel Source Number and the IP Display
Name is used as the Tel Display Name. If no Display Name is
received from IP, the Tel Display Name remains empty.

[1] Yes = If an IP Display Name is received, it is used as the Tel
