User's Manual 47. Selected Technical Specifications
Function Specification
Interfaces
Telephony Interface
1, 2, 4, 8 or 16 E1/T1/J1 Balanced 120/100 Ohm, or 75 Ohm using a
BNC to RJ-45 dual E1/T1 G.703 Balun adapter.
Note: The following Balun adaptors were tested and certified by
AudioCodes:
 Manufacture Name: AC&E (Part Number: B04040072)
 Manufacture Name: RIT (Part Number: R3712271)
Network Interface
Two 10/100Base-TX, half or full duplex with auto-negotiation
LED Indicators
LED Indications on Front
Panel
Power, ACT/Fail, T1/E1 status, Ethernet status, Swap ready indication
Connectors & Switches
Rear Panel
Trunks 1 to 8 and 9 to 16
Two 50-pin female Telco connectors (DDK57AE-40500-21D) or 8 RJ-
48c connectors for trunks 1 to 8 only
Ethernet 1 and 2
Two 10/100Base-TX, RJ-45 shielded connectors
AC Power
 Standard IEC320 Appliance inlet
 Dual (fully redundant) power supply (optional)
DC Power
 2-pin terminal block (screw connection type) suitable for field wiring
applications connecting DC Power connector MSTB2.5/2-STF (5.08
mm) from Phoenix Contact
 Bonding and earthing: 6-32-UNC screw is provided - correct ring
terminal and 16 AWG wire minimum must be used
 Or crimp connection (see note below)
Note: To meet UL approval, customers must fulfill the criteria below:
2-pin terminal block (crimp connection type) comprising a Phoenix
Contact
 Adaptor: Shroud MSTBC2,5/2-STZF-5,08
 Contacts: MSTBC-MT0,5-1,0
 Cable: 18 AWG x 1.5 m length
Physical
AC Power Supply
 Single universal power supply 100-240V 1.5A max, 50-60 Hz
 Dual redundant power supply (optional)
AC Power Consumption
 1 or 2 span: 39.7 W
 4 spans: 42.1 W (approx.)
 8 spans: 45.3 W
 16 spans: 61.5 W
DC Power Supply
(optional)
36 to 72 VDC (nominal 48 VDC), 4A max, floating input
DC Power Consumption
 1 or 2 span: 28.8 W
 4 spans: 32.8 W
 8 spans: 36.4 W
Environmental (DC)
 Operating Temp: 0 to 40°C (32 to 104°F)
 Short Term Operating Temp (per NEBS): 0 to 55°C (32 to 131°F)
