AudioCodes Mediant 2000

User's Manual 700 Document #: LTRT-68822
Mediant 2000
Function Specification

Storage: -40 to 70°C (-40 to 158°F)
 Humidity: 10 to 90% non-condensing
Environmental (AC)
 Operating Temp: 0 to 40°C (32 to 104°F)
 Storage: -40 to 70°C (-40 to 158°F)
 Humidity: 10 to 90% non-condensing
Hot Swap
 Blades are full hot-swappable
 Power supplies are redundant, but not hot-swappable
Enclosure Dimensions
445 x 44 x 300 mm (17.5 x 1.75 x 12 inches)
Weight
Approx. 4.8 kg fully populated (16 spans); 4.2 kg for 1 span
Installation
1U 19-inch 2-slot chassis; rack-, shelf-, or desktop-mount options.
Rack mount using two side brackets - 2 additional (rear) side brackets
optional
Diagnostics
Front panel Status LEDs
 E1/T1 status
 Ethernet status
 Status of device (Fail, ACT, Power, and Swap Ready)
Syslog events
Supported by Syslog Server, per RFC 3164 IETF standard.
SNMP MIBs and Traps
SNMP v2c; SNMP v3
Management
Configuration
Configuration of device using Web browser or ini files
Management and
Maintenance
 SNMP v2c; SNMP v3
 Syslog (RFC 3164)
 Web Management (via HTTP or HTTPS)
 Telnet
Type Approvals
Telecommunication
Standards
 IC CS03; FCC part 68
 Chassis and Host telecom card comply with IC CS03; FCC part 68;
CTR 4, CTR 12 & CTR 13; JATE; TS.016; TSO; Anatel, Mexico
Telecom, Russia CCC, ASIF S016, ASIF S038
Safety and EMC
Standards
 UL 60 950-1, FCC part 15 Class B, (Class A with SUN 2080 CPU
card)
 CE Mark: EN 55022 Class B (Class A with SUN 2080 CPU card),
EN 60950-1, EN 55024, EN 300 386
 TS001
Environmental
 NEBS Level 3: GR-63-Core, GR-1089-Core, Type 1 & 3. Approved
for DC powered version
 Complies with ETS 301019; ETS 300019-1, -2, -3. (T 1.1, T 2.3,
T3.2)
 Approved for AudioCodes or DC powered versions
