Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
134
of 820
4.4
The exact correlation between the torque current and the torque is shown in the torque
monitoring (
ZFig. 174– on page 524).
107.68 Load inertia
(from Firmware version 01.11)
Load inertia can be used for the calculation of the parameters of the speed controller from
the data sheet in ProDrive. The parameter is not part of the electronic type plate and must
be entered manually.
107.72 Continuous current limit curve
The supporting points of the continuous current limit characteristic (motor duty type: S1)
are entered in 107.72[0] to 107.72[10]. 107.72[0] and must include the standstill current
value (
Z107.10–), while in other elements the current values must be entered in a fixed
distance of a maximum speed mechanical (Z107.26–) divided by 10.
The selection and the entering of the values can be made manually or by an available
supporting point set in the Baumüller motor data base. Generally, the supporting points
107.72[0] to 107.72[10] are assigned zero.
The parameter can be changed in the inhibited state, only.
128.1 Motor temperature status
Status of the motor temperature measurement and monitoring:
Kt factor
M
nom
I
sq-nom
---------------=
Bit Meaning
0 0: Motor temperature monitoring switched off
1: Motor temperature monitoring switched on
3 ... 1 Reserved
4 1: Warning threshold 1 exceeded
5 1: Warning threshold 2 exceeded
6 1: Switch-off temperature reached
7 1: Overtemperature detected by temperature switch
8 1: Short circuit detected on temperature encoder
9 1: Temperature encoder is not connected
15 ... 10 Reserved
