Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
140
of 820
4.4
138.7 Iq lower limit
Display of the currently determined lower limit for the instantaneous current [in A].
138.8 Bitmask of external drive current limit
Display of external sources of the drive current limit as a bit string.
A 1 in the corresponding bit position means that the limit is active.
If several bits are set, the smallest limit takes effect.
Meaning of the bits and the external source of the drive current limiting:
138.9 External limiting max. drive current
Display of the total current [in A] which has been reduced by an external limit. See Bitbar
of external current limit
Z138.8–.
It the external limit is not active:
External limiting max drive current >138.9< = Maximum value (10000 A)
138.10 External limiting max. field current amplitude
Display of the field current [in A] which has been reduced by an external limit of the drive
current. See "Bit mask of external drive current limit"
Z138.8–.
If there is no external limit active:
External limiting max field current amplitude >138.10< = Maximum value (10000 A)
138.11 Iq set value before notch filter
The Iq set value at the input of the notch filter is shown in this parameter.
Bit Current limit from
0 Main power error; phase failore
1 Reserved
2 PU overload monitoring
3 Reserved
4 Moving to positive stop command
5 Homing to a mechanical stop
15 ...6. Reserved
