Page #204 background imageLoading...
Page #204 background image
Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
204
of 820
4.4
123.8 Result current controller Kp
This parameter shows the calculated current controller Kp value at a PWM frequency of
4 kHz.
123.9 Result current controller Tn
This parameter shows the identified reset time for the current controller.
123.10 Parameters takeover
The identified parameters are used internally for the motor control, if bit 3 is active.
The following parameters are written to:
1 Z47.7 P-gain Iq = Z47.9 P-gain Id
The P-gains entered always refer to 4 kHz PWM. The adjustment of the PWM fre-
quency to other frequencies takes place internally, automatically.
2 Z47.8 Reset time Iq = Z47.10 Reset time Id
3 Motor parameters that are relevant to decoupling feedforward, IxR feedforward and
current prediction in the current controller:
Synchronous motor
Z107.29 Stator resistance
Z107.34 Inductance Lq
Z107.35 Inductance Ld (with Parameter 107.35 = Parameter 107.34)
Asynchronous motor
Z107.29 Stator resistance
Z107.30 Stator leakage inductance
Bit no. Meaning
0 Reserved
1 Accept identified Lh-characteristic
2 Smooth the dead time table
3 Parameter for motor control from:
0: Motor type plate
1: Identification
NOTE!
There is no way to prove, if autotuning was successful.
