Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
224
of 820
4.4
117.5 Bit selection digital output 1
Bit selection for digital output 1. The bit selection also applies to Float parameters. It
therefore makes sense to fix the bit selection to FFFFFFFF
hex
for parameters of data type
Float.
117.6 Compare bit pattern digital output 1
Bit pattern that will be compared with the bit pattern of the source parameter for Digital
Output 1
117.7 Mode digital output 2
For description, see Z117.2–.
117.9 Source number digital output 2
For description, see Z117.4–.
117.10 Bit selection digital output 2
For description, see Z117.5–.
117.11 Compare bit pattern digital output 2
For description, see Z117.6–.
117.22 Mode
This parameter is used to set the behavior for the triggering of the digital outputs.
Bit # Meaning
0 0: Transparency mode off: The outputs are triggered via connections. 
1: Transparency mode active: The outputs are triggered via Z117.23–.
31 ... 1 Reserved
