Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
250
of 820
4.4
131.5 Producer counter
The number of accesses to the Producer and Consumer lists is represented in each case
as a one-dimensional array. The access counters are writable parameters, so that the
counter statuses can be set externally, e.g. to 0.
Using the two parameters Last Producer Index (Z131.7–) and Last Consumer index
(Z131.8–) it is possible to display separately for Producer and Consumer, which list was
last accessed in each case.
The index corresponds to the number of the accessed real-time list. At present, a maxi-
mum of only 2 lists is possible.
131.6 Consumer counter
see Z131.5–
131.7 Last producer index
The index of the list that was last accessed is displayed.
131.8 Last consumer index
The index of the list that was last accessed is displayed.
131.9 Slave settings
The settings for the communications software (MicroBlaze) can be altered by setting bits.
Bit no. Description
0 1: Read network settings for the EoE (Ethernet over EtherCAT) of Parame-
ters 131.14, 131.16, 131.17
0: IP address = base IP address + DIP-switch value (131.12 + 131.13),
Gateway = 0.0.0.0, Subnet mask = 255.255.0.0
1 Select a language online at CoE object directory
1: English
0: German
13 ... 2 Reserved
14 0: Do not activate Factor Group
1: Activate Factor Group
