Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
262
of 820
4.4
124.3 Status
Status of the measuring encoder.
Bit Meaning
Encoder 1
0 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP1 positive edge
1 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP1 negative edge
2 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP2 positive edge
3 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP2 negative edge
4 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger Zero
Pulse positive edge
5 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger Zero
Pulse negative edge
6 ... 15 Reserved
Bit Meaning
0 Measured value storage Measurement Channel "Encoder 1 with Trigger
digital input TP1 positive edge":
0: Switched off
1: Switched on
1 Measured value storage Measurement Channel "Encoder 1 with Trigger
digital input TP1 negative edge":
0: Switched off
1: Switched on
2 Measured value storage Measurement Channel "Encoder 1 with Trigger
digital input TP2 positive edge":
0: Switched off
1: Switched on
3 Measured value storage Measurement Channel "Encoder 1 with Trigger
digital input TP2 negative edge":
0: Switched off
1: Switched on
