Attention:
The status bits 12…17 and 20…21 remain set with continuous triggering of the corre-
sponding channel (P124.1) after the first measurement. For signaling, the additional use
of P124.4 is recommended where new measured values of the channels are signaled
through toggle bits.
4 Measured value storage Measurement Channel "Encoder 1 with Trigger
Zero Pulse positive edge":
0: Switched off
1: Switched on
5 Measured value storage Measurement Channel "Encoder 1 with Trigger
Zero Pulse negative edge":
0: Switched off
1: Switched on
11 ... 6 Reserved
12 Status of the measured value storage Channel "Encoder 1 with Trigger digi-
tal input TP1" ("or" linked Bits 20,21):
0: No measured value stored yet
1: Measured value stored
13 Status of the measured value storage Channel "Encoder 1 with Trigger digi-
tal input TP2" ("or" linked Bits 22,23):
0: No measured value stored yet
1: Measured value stored
14 Status of the measured value storage Channel "Encoder 1 with Trigger Zero
Pulse " ("or" linked Bits 24,25):
0: No measured value stored yet
1: Measured value stored
19…15 Reserved
21…20 Status of measured value storage Measurement Channel "Encoder 1 with
Trigger digital input TP1":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
23…22 Status of measured value storage Measurement Channel "Encoder 1 with
Trigger digital input TP2":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
25…24 Status of measured value storage channel "Encoder 1 with Zero Pulse":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
31…25 Reserved
