Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
264
of 820
4.4
124.4 Status 2
Extended status of the measuring encoder.
Toggle bits to signal new measurements with continuous triggering (refer to Z124.1–).
The corresponding bit changes its status with each new measurement.
124.5 Encoder 1 trigger digital input TP1 pos. edge revolutions
Revolutions Encoder 1 with triggering of measurement through rising edge at digital input
TP1.
124.6 Encoder 1 trigger digital input TP1 pos. edge angle
Angle Encoder 1 with triggering of measurement through rising edge at digital input TP1.
124.7 Encoder 1 trigger digital input TP1 neg. edge revolutions
Revolutions Encoder 1 with triggering of measurement through falling edge at digital input
TP1.
Bit Meaning
0 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger digital input TP1 positive edge" exists.
0->1, 1->0: new measured value exists
1 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger digital input TP1 negative edge" exists.
0->1, 1->0: new measured value exists
2 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger digital input TP2 positive edge" exists.
0->1, 1->0: new measured value exists
3 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger digital input TP2 negative edge" exists.
0->1, 1->0: new measured value exists
4 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger Zero Pulse positive edge" exists.
0->1, 1->0: new measured value exists
5 Toggle bit to signal "New measured value in channel "Encoder 1 with Trig-
ger Zero Pulse negative edge" exists.
0->1, 1->0: new measured value exists
6…31 Reserved
