Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
358
of 820
4.5
108.14 SHUTDOWN reaction code
See also ZDrive management– from page 330
This parameter defines the response of the drive during the transition from the OPERA-
TION ENABLED to the READY TO SWITCH ON state in the state machine for the device
controller.
For correct functioning of the braking procedures on the Quick Stop or Ramp-down
ramps, the speed controller must be adequately configured.
108.15 DISABLE OPERATION reaction code
See also ZDrive management– from page 330
This parameter defines the response of the drive during the transition from the OPERA-
TION ENABLED to the SWITCHED ON state in the state machine for the device control-
ler.
For correct functioning of the braking procedures on the Quick Stop or Ramp-down
ramps, the speed controller must be adequately configured.
108.16 Status internal limits
Status bit string for internal limits 
Value Meaning
0 Inhibit drive immediately
1 Return to ramp-down ramp
2 Return to Quick Stop ramp
3 Return to current limit
Value Meaning
0 Inhibit drive immediately
1 Return to ramp-down ramp
2 Return to Quick Stop ramp
3 Return to current limit
Bit no. Meaning
0 1: Current/torque limited
1 1: Speed set value limited at speed controller input
2 1: Speed limited during set value generation
