Set Value Generators

Parameter manual b maXX BM3000

Document no.: 5.12001.07 Baumüller Nürnberg GmbH

434

of 820

4.6

159.2 Cam options

Settings of the different operating modes and functions of the cam generator.

3 Stops the processing at time-controlled processing. As soon as the bit is

reset, processing is started again at the same point (interrupt function).

0: Time-controlled processing is running

1: Time-controlled processing is stopped

4 … 6 Reserved

7 The actual valid cam is invalidated. There is no valid cam available in the

RAM of the controller.

0 1: The actual cam is deleted in the RAM

Bit no. Meaning

0 0: time-controlled processing

1: parameter-controlled processing

1 Time-controlled processing, only

0: time control via the table index

1: time control with virtual master axis

2 Time control with virtual master axis and parameter-controlled processing,

only

0: no interpolation

1: active interpolation

3 Time control with virtual master axis and parameter-controlled processing,

only

0: linear interpolation

1: square interpolation

4 0: specify cyclical offset manually

1: generate cyclical offset from the cam

5 0: processing one-time only

1: cyclical processing

6 0: real time mode

1: relative mode

7 Parameter-controlled processing, only

0: no auto offset

1: active auto offset
