159.3 Status
Displays the actual state of cam generator.
159.4 List index
The instantaneously active table entry is displayed.
This index starts at 0 and ends at (count supporting points - 1).
159.5 List entries
Total count of supporting points of the active cam.
159.6 Cyclic curve offset
Cyclical curve offset see chapter ZCyclical curve offset– on page 429.
159.7 Reference parameter
Reference parameter, which is used for the relative mode or for the real time offset. Infor-
mation see chapter ZRelative mode– on page 430.
159.9 Speed virtual master axis
Speed of the virtual master axis. Speed of 256 accords to a processing of a table index
per work cycle. At a negative speed the cam will run the opposite direction.
Bit no. Meaning
0 … 1 00: "init" state (parameterization is possible)
01: "active" state (parameterization completed and advisable)
11: "run" state (cam processing is running)
2 … 5 Reserved
6 0: no valid cam in the RAM
1: valid cam in the RAM
7 0: the output is between the minimum and the maximum value of the tar-
get parameter
1: the output was limited
