Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
463
of 820
4
18.58 Position set value angle
The parameter displays the angle in the position set value in 32-bit resolution per revolu-
tion.
18.59 Position set value revolutions
The parameter displays the number of revolutions in the position set value in 32-bit reso-
lution.
18.60 Position error rev+angle
Display of the position error in 32-bit integer format. The lower 16 bits correspond to the
angle and the upper 16 bits to the revolutions.

The angular resolution here is approx. 0.0055 degrees.
Revolutions
31 ........................ 16
Angle
15 .......................... 0
Z18.57–
 
Revolutions
31 ............................................................... 0
Angle
31 ............................................................... 0
Z18.59– Z18.58–
Revolutions
31 ........................ 16
Angle
15 .......................... 0
Z18.60–
 
Revolutions
31 ............................................................... 0
Angle
31 ............................................................... 0
Z18.62– Z18.61–
