Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
615
of 820
4
149.9 Spindle relative offset
The parameter is used as distance which must be driven from standstill at relative se-
quential positioning (Z149.2– Mode bit 4 = 1). Only the Low-Word of the parameter is
used. The High-Word of the parameter is not used at the time and must be set to zero.
Format High-Word: Revolutions Low-Word: Angle
Figure 207: Spindle relative offset
149.10 Active target position
This is the calculated target position, which must be reached in a 16 bit revolution and in
a 16 bit angle format.
The parameter is updated in the operating modes spindle positioning (-6) and target po-
sition setting (1).
149.11 Output position set value
This parameter shows the actual position set value calculated from module spindle posi-
tioning.
149.12 Output speed set value
This parameter shows the output speed set value generated from module spindle posi-
tioning.
149.13 Output acceleration set value
This parameter shows the output acceleration set value generated from module spindle
positioning.
5000_0174_rev01_int.cdr
><18.59 ><18.58
63 31
0
31
16 0
64 Bit position setpoint
Revolutions
Angle
Relative offset
