Error descriptions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
752
of 820
5.5
411 Overcurrent EnDat
®
interface The error is triggered by the module EnDat
®
interface when the
absolute encoder reports via the EnDat
®
interface that the encoder
supply current is too high.
m Cause:
Cause for a encoder supply current that is too high may be an
internal short circuit.
n Remedy:
Replace encoder.
Pulse block
412 Battery error EnDat
®
interface The error is triggered by the module EnDat
®
interface when the Mul-
titurn absolute encoder reports via the EnDat
®
interface that the sup-
ply battery must be replaced. The battery voltage provides position
information for the Multiturn encoder in the memory when the con
-
troller is switched off and no supply voltage is provided for the
encoder.
m Cause:
Cause for a battery replacement in the Multiturn encoder may be
a modification of the battery.
n Remedy:
Replace encoder.
Pulse block
413 Alarm Bit set EnDat
®
interface has set alarm Bit (collective message). Pulse block
414 Error during reception: Address mirror-
ing returns an error
Error during reception: Address mirroring returns an error Pulse block
415 Variance of encoder signals exceeds
adjustable limit
The variance of encoder signals exceeds adjustable limit Pulse block
416 Touch probe: trigger zero pulse without
incremental encoder
The touch probe measurement is configured to trigger by a zero
pulse, but the used encoder does not provide a zero pulse.
m Effect:
Value is not accepted
Response parameterizable
n Acknowledgment:
No particular action
No response
417 Warning Collision of frequency EnDat
®
encoder has messaged warning collision of frequency, see
Z137.38–; preventative maintenance is recommended.
No response
418 Warning Excess temperature EnDat
®
encoder has messaged warning excess temperature; see
Z137.38– and error number 407; preventative maintenance is rec-
ommended.
No response
419 Warning Lighting controller reserve
reached
EnDat
®
encoder has messaged warning „Lighting controller reserve
reached“; see
Z137.38– and error number 406; preventative main-
tenance is recommended in order to avoid lighting failure.
No response
420 Warning Battery load to small EnDat
®
encoder has messaged warning „Battery load to small“; see
Z137.38– and error number 412; preventative battery change is rec-
ommended.
No response
421 Warning Reference point EnDat
®
encoder has messaged warning Reference point; see
Z137.38–; preventative maintenance is recommended.
No response
422 Parity errors in received data Parity errors in the received data of SSI Pulse block
423 Received data invalid Received data of SSI encoder are invalid. Pulse block
428 Encoder monitoring: difference
between analog and digital position too
high
Hiperface encoders: The absolute position is read via the serial hip-
erface interface and compared to the analog position calulated from
the analog SinCos signals by the FPGA. If the position errors abso
-
lute value (Z14.22–) is higher than the defined error threshold
(Z14.21–) this error is set.
Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
