Error descriptions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
760
of 820
5.5
1003 Overcurrent error in the power unit The limit of the maximum current of the power unit is exceeded in
one of the three phases.
In the additional information 1 of the error message is shown in
which channel the overcurrent was recognized:
1: Channel A, positive
2: Channel A, negative
3: Channel B, positive
4: Channel B, negative
5: Channel C, positive
6: Channel C, negative
m Cause/ Remedy:
Check motor leads
Check motor connection
Pulse block
1006 Power unit excess temperature If the power unit exceeds a power unit dependent cut-off tempera-
ture, the power unit will be blocked.
m Cause / Remedy:
Check function of fan power unit
n Effect:
The error is fatal and leads to the immediate deactivation of the
drive controller. The drive will fizzle out, if applicable. Controller
activation for the drive again will be prevented until the error
cause has been eliminated and the error has been reset.
Pulse block
1007 Power unit safety relay The error is triggered when the voltage supply of the transistor acti-
vation in the power unit is switched off through the safety relay with
activated control activation.
To avoid error messages when activating a drive, comply with the
activation sequence specified in the documentation.
m Effect:
The error is fatal and leads to the immediate deactivation of the
drive controller. The drive will fizzle out, if applicable. Controller
activation for the drive again will be prevented until the error
cause has been eliminated and the error has been reset.
Pulse block
1010 Bit bar power unit cannot be read When multiple errors occur on the converter and power unit, the
evaluation of the bit bar of the power unit interface will display the
differentiation of the errors. If the bit bar cannot be read out, the error
message will be generated.
This error is provided for monitoring the deactivation sequence.
m Effect:
The error is fatal and leads to the immediate deactivation of the
drive controller. The drive will fizzle out, if applicable. Controller
activation for the drive again will be prevented until the error
cause has been eliminated and the error has been reset.
Pulse block
1013 Deactivation through safety technology The drive function is disabled by the safety technology (Safe Torque
Off)
Pulse block
1014 DSP Timeout error because the DSP
has not updated the Pot ABC Registers
DSP Timeout error because the DSP has not updated the Pot ABC
Registers
Pulse block
1015 Phase error timeout At phase failure an error occurs, if the switch-off is selected accord-
ing to period (P130.10) and the time expired (P130.24). Pulse inhibit
(0) immediately must be executed, because the pulses must be
inhibited
IMMEDIATELY after the error occurred.
Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
