Error messages and troubleshooting
Parameter manual b maXX BM3000
Document no.: 5.12001.07
761
of 820
5
1016 Mains failure (Mono unit) If the device signals „Mains failure“, the error 1016 is set by the drive
manager in the transition „Ready to switch-on“ (2) to „Switch-on“ (3).
Further details see >130.25< Mains Failure Delay
Pulse block
1019 Undervoltage DC link voltage Error Undervoltage DC link voltage is detected through the FPGA.
Setting the error bit in the FPGA and activating the error message
only occurs when the pulses are activated. The pulses will then be
blocked in the FPGA. Therefore, the only permitted response is the
pulse block.
Pulse block
1020 Heat sink excess temperature Switch off due to exceeding of the maximum heat sink temperature
from parameter 129.26
Pulse block
1021 Excess temperature inside tempera-
ture
Switch off due to exceeding of the maximum heat sink temperature
from parameter 129.27
Pulse block
1022 Cable break heat sink temperature
encoder
Pulse block
1023 Communication error with MUX regis-
ter to the FPGA
Communication error with Multiplex Register interface to the FPGA Pulse block
1024 Current offset error The error will be triggered when the measured current offset is
greater than 5% of the possible measuring range of the AD con
-
verter. Only one phase must thereby indicate this error.
Pulse block
1025 Setting of pulse enable (IF) and PWM
not synchronous with DSP
The error is triggered when the PWM counter is no longer synchro-
nous with the DSP Interrupt system and the pulse activation has
been enabled.
Pulse block
1026 Chopper resistor overtemperature The error is enabled if the chopper resistor temperature (calculated
model).
Pulse block
1027 Supply connection detected at exter-
nal supply
External supply is parameterized (Z130.10– Bit 0 = 1) via the power
unit mode. The device has at least one phase at the connection
X202 (b
maXX 3200/3300). This operating status is not permitted,
because the shunting relay of the charging resistor is open at exter
-
nal supply.
m Effect:
Pulse inhibit, because power supply via the supply connection
X202 can destroy the device.
Pulse block
1032 Error DC-link supply DC-link undervoltage detected (Z130.35– / Z130.36– / Z130.37–)
or signal "supply ready for use" of the Signal Bus is low.
Pulse block
1035 No valid Lt data available The power unit data is not complete or it is not existent or it could not
be read completely.
Pulse block
1046 Warning: Deactivation through safety
technology
The safety function Safe Torque Off is active No response
1047 Warning: Phase failure This warning is set if a phase failure is recognized.
The warning will be deleted automatically as soon as the phase fail-
ure is no more existent and the error response „no response“ is set
for this message. If a drive reaction is set, the error must be reset.
No response
1048 Warning: Mains failure / Supply not
ready
A mains failure was detected or the supply is not ready-to-operate.
The warning is triggered independent of the drive state. If the drive is
enabled, the error 1016 (Mains failure) or 1032 (Error DC-link sup
-
ply) is generated at the end of the Mains failure delay.
Further details see Z130.25– Mains failure delay
No response
1049 Temperature warning threshold heat
sink exceeded
Temperature warning threshold heat sink exceeded No response
1050 Temperature warning threshold Inside
Air exceeded
No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
