Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
100
of 820
4.4
130.9 Fan mode
130.10 Mode
Settings for the mains rectifier unit.
The parameter is changeable only in locked status.
Bit 1:
Bit 1...0 Meaning
00 Fan control dependent on heat sink and ambient temperature
01 Fan control dependent on the presence of main supply voltage
10 Fan is always switched off
11 Fan is always switched on
Bit no. Meaning
0 0: Supply from the mains via X202
1: Supply via X205
1 Behavior at mains failure:
0: The motorized operation is inhibited at mains failure
1: Motorized operation is possible if there is a mains failure
This setting is only permitted at external supply. A motorized operation is
not possible at internal supply.
2 0: Limitation of the motor current to Z129.25– Current phase error; no
shutdown
1: Limitation of the motor current to Z107.9– Nominal current, shutdown
of the drive after the duration in Z130.24– Phase error delay time
3 Reserved
4 0: Three-phase supply to X202
1: Single-phase supply to X202
If this bit is set, the message 1047 „Warning Phase Failure“ is sup-
pressed. Bit 2 may not be set at the same time!
5 Automatic restart after mains failure:
0: At mains failure the drive remains enabled for the time set in Z130.25–
Mains failure delay. According to the setting of bit 1 the motor operation
is disabled internallly.
1: At mains failure the pulses are inhibited at once and the drive changes
in the "Switch-on inhibit" state. If mains is available again within the set
time in Z130.25–, the drive is enabled automatically (automatic restart).
It is essential generally: If the mains failure is longer than the set time in
Z130.25– an error message is generated.
15 ... 6 Reserved
