Error descriptions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
762
of 820
5.5
1054 DSP Timeout Error: DSP does not
write the PWM Pot Registers in time, 3
times within 100 ms
DSP Timeout Error: DSP does not write the PWM Pot Registers in
time, 3 times within 100 ms
Pulse block
1055 DC link voltage chopper threshold (DC
link voltage max-30V) exceeded
The chopper threshold (DC link voltage Max-30V) was exceeded
during DC link voltage monitoring
No response
1056 Performance element 24 V Fail When the 24V supply voltage drops below a specific threshold the
FPGA will activate a corresponding error bit in its status and block
the pulses.
Pulse block
1057 15 V fail - power cycle required The 15 V power supply failed. Pulse block
1066 SS1 stop forced by SAF module If SS1 function is activated on SAF-002/-003 module and an appro-
priate error occurs, the SAF module forces the SS1 stop function on
the controller.
No response
1100 Drive manager general error pulse
enable
Drive is enabled and the pulses are inhibited without an accordant
error message.
Pulse block
1106 Drive operation mode not allowed with
this motor operation mode
Drive operation mode not allowed with this motor mode operation
mode. error caused when changing from state 3 to 4.
m Effect
Drive is not started
m Error reset
Error can be reset
Pulse block
1107 In this operation mode it is possible to
change to operation mode 4
In this operation mode it is possible to change to operation mode 4.
No online change possible e.g. from speed control to find notch posi
-
tion.
No response
1300 Memory organization is faulty. No response
1301 Invalid trigger configuration (both
edges)
Invalid trigger configuration in the ring buffer. Triggering to both
edges is not possible.
No response
1302 no Trigger ID entered no Trigger ID entered No response
1303 no ID to read out data no ID to read out data No response
1304 no permission to read out data No response
1305 No record for channel and axis No record for channel and axis No response
1400 Error while loading or saving the data
record
Error while loading or saving the data record Pulse block
1401 No valid parameter file found No valid parameter file found Pulse block
1402 CRC in parameter file not correct CRC in parameter file not correct Pulse block
1403 Invalid data record number indicated
for DSV command
An invalid data record number was indicated for a data record com-
mand.
The error is reported when an attempt is made to switch to a non-
existing data record, delete the active data record or copy the values
from a non-existing data record.
No response
1500 uBlaze Software has a critical error It was an critical error and µBlaze Software is no longer functional No response
1501 If there is no response from the slave
(HPI-Buffer Initialization)
Slave did not respond within specified time.
Master Ident Code = 0xDEADBEEF
Slave Ident Code = 0xBEEFDEAD
No response
1502 Message length is greater than HPI
Buffer
Message length is greater than HPI Buffer No response
1503 Access to HPI wrong channel Access to the wrong (non-existent) HPI-Channel No response
1504 HPI Channel was not initialized First Access to the HPI-channel was early as the initialization. No response
1505 HPI buffer is empty HPI buffer has no user data available. No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
