Baumuller b maXX BM3000 User Manual

Error messages and troubleshooting
Parameter manual b maXX BM3000
Document no.: 5.12001.07
763
of 820
5
1506 HPI buffer is full HPI buffer has user data available or old telegram data are not
called for yet.
No response
1507 TCP IP Stack could not be initialized An error has occurred at initialization of TCP/IP stack No response
1508 SoE firmware error message SoE firmware (Servodrive-Profile over EtherCAT) sends an error
message to the drive controller. The error reaction is started by the
SoE firmware of the fieldbus processor.
No response
1509 EtherCAT IP core cannot init EEPROM No response
1510 Sub device index invalid Sub device index invalid, i.e. out of range No response
1511 Firmware error fieldbus controller Fieldbus controller signaled a firmware error. No response
1512 Faulty backup of operation data No response
1513 Illegal drive address A invalid drive address is set. No response
1514 Error caused by memory allocation No response
1515 Faulty task start Operating system was not able to start a task. No response
1516 Faulty init of scaling data No response
1517 Error during reading of the cyclic actual
values
No response
1518 Error during writing of the cyclic set val-
ues
No response
1519 Critical GDP error while initialization Incorrect reading or writing of important data via GPD. GPD means
the communication between controller and fieldbus controller.
No response
1520 Invalid version of the controller firm-
ware
Installed controller firmware cannot be used with this type of field-
bus. Version see controller parameter P102.2 or IDN P-0-0221
No response
1521 Warning: Error while reading service
data
No response
1522 Warning: Error while writing service
data
No response
1523 Error during command execution An error occurred during a command execution. No response
1524 Timeout during command execution A timeout occurred during a command execution. No response
1525 MST-Error; drive controller lost syn-
chronization
Sercos: MST incorrect
SoE: controller signaled lost synchronization
No response
1526 Error: MDT miss twice; watchdog time-
out process data
Sercos: failure of MDT (MDT miss twice)
SoE: watchdog timeout at process data
No response
1527 Error during switch up of phase Error during switch up of the bus state
(phase switch up)
No response
1528 Error during switch down of phase Error during switch down of the bus state
(phase switch down)
No response
1529 Phase transition without ready
acknowledge
Sercos:
n switch up to CP3 not possible  back to CP0.
n switch up to CP4 not possible  back to CP0.
SoE:
n switch up to Safe-Op not possible  back to Pre-OP.
n switch up to Op not possible  back to Safe-OP.
No response
1530 Error: Invalid phase Invalid phase (bus state) set. No response
1531 Switch to non-initialized operation
mode
Switch to a not supported or unknown operation mode. No response
1532 Error: Two drives with same address in
ring
Error message only possible using Sercos. No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
