Baumuller b maXX BM3000 User Manual

Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
804
of 820
6
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
168.4 Upper Limit INT -16384 16384 16384 % 16384:
100
X
168.5 Lower Limit INT -16384 16384 -16384 % 16384:
100
X
168.6 Increment INT 0 2000 100 % 100:1 X
170.1 PLC control word UINT 0 0xFFFF 0 1:1 X
170.2 PLC status UINT 0 0xFFFF 0 1:1 X
170.3 Task control word UDINT 0 0xFFFFFFFF 0xFFFFFFFF 1:1 X X
170.4 Task status UDINT 0 0xFFFFFFFF 0 1:1
170.5 Run time default task FLOAT 0 5000000000 0 µs 1:1 X
170.6 Translation control WORD 0 0xFFFF 0 1:1
170.7 Cycle time default task FLOAT 0 5000000000 0 ms 1:1 X
170.10 Project name STRING 1:1 X
170.11 Project time stamp STRING 1:1 X
170.12 Free memory UDINT 0 0xFFFFFFFF 0 1:1 X
170.13 POU count UINT 0 0xFFFF 0 1:1 X
170.14 Task count UINT 0 0xFFFF 0 1:1 X
170.15 Project CRC UDINT 0 0xFFFFFFFF 0 1:1 X
170.16 MetaData CRC UDINT 0 0xFFFFFFFF 0 1:1 X
170.20 Write event parameter UINT UINT 0 0xFFFF 0 1:1 X
170.21 Write event parameter
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
170.22 Write event parameter REAL FLOAT 0 0xFFFFFFFF 0 1:1 X
170.30 Error code UDINT 0 0xFFFFFFFF 0 1:1 X
170.31 Error module number UINT 0 0xFFFF 0 1:1 X
170.32 Error line number UINT 0 0xFFFF 0 1:1 X
170.33 Error POU Code type UINT 0 0xFFFF 0 1:1 X
170.34 Error module name STRING 1:1 X
170.50 Run time task RT0 FLOAT 0 5000000000 0 µs 1:1 X
170.51 Run time task RT1 FLOAT 0 5000000000 0 µs 1:1 X
170.52 Run time task RT2 FLOAT 0 5000000000 0 µs 1:1 X
170.53 Run time fieldbus task FLOAT 0 5000000000 0 µs 1:1 X
170.54 Run time write event task FLOAT 0 5000000000 0 µs 1:1 X
171.1 Control word reluctance UINT 0 0xFFFF 0 1:1
171.3 Ld curve family FLOAT 1e-5 1e9 1e-3 mH 1:1000 X
171.4 Lq curve family FLOAT 1e-5 1e9 1e-3 mH 1:1000 X
171.5 Norm current for inductance
chart familiy
FLOAT 0.01 1e9 10 A 1:1 X
171.10 Minimum Id Current FLOAT -1e9 0 0 A 1:1 X
171.11 Id Current of MTPF charac-
teristic
FLOAT -100 0 -100 A 1:1 X
171.12 Motor constant K FLOAT -1 1e9 -1 A 1:1 X
171.13 MTPF Table FLOAT -100 0 -100 % 1:1 X
171.14 Nominal flux FLOAT 0.0001 1e9 1 Vs 1:1 X
