Baumuller b maXX BM3000 User Manual

Summary of all Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
805
of 820
6
171.15 State field weakening of
IPMSM
DINT 0 10 0 1:1 X
171.16 Total reference current FLOAT -10000 10000 0 A 1:1 X
171.17 Maximal torque current from
flux
FLOAT 0 10000 0 A 1:1 X
171.20 Magnetic flux FLOAT 0.0001 1e9 0.1 Vs 1:1 X
171.21 State identification nonlinear-
ity
UINT 0 0xFFFF 0 1:1 X
175.1 Mode PU temperature model UINT 0x0 0xFFFF 0x0 1:1 X
175.2 Status PU temperature
model
UINT 0 0xFFFF 0 1:1 X
175.3 Max. device control cabin
temperature
UINT 0 55 40 Grad
C
1:1 X
175.4 Max. device altitude UINT 0 5000 1000 m 1:1 X
175.5 Max. device mains voltage UINT 0 530 400 V 1:1 X
175.6 Max. device DC link voltage UINT 0 760 540 V 1:1 X
175.7 PU max.continuous current
actual value
FLOAT 0 1000 4 A 1:1 X
175.8 PU I2t max. continuous cur-
rent actual value
FLOAT 0 1000 4 A 1:1 X
175.15 Power unit thermal load FLOAT 0 1000 0 % 1:1 X
179.1 Polarity UINT8 0 0xFF 0 1:1 X
179.2 Position resolution encoder
increments
UDINT 1 4294967295 65536 Inc 1:1 X
179.3 Position resolution motor rev-
olutions
UDINT 1 4294967295 1 1:1 X
179.4 Velocity resolution encoder
increments/s
UDINT 1 4294967295 65536 Inc/s 1:1 X
179.5 Velocity resolution motor rev-
olutions/s
UDINT 1 4294967295 1 1/s 1:1 X
179.6 Gear ratio drive shaft revolu-
tions
UDINT 1 4294967295 1 1:1 X
179.7 Gear ratio drive shaft revolu-
tions
UDINT 1 4294967295 1 1:1 X
179.8 Feed constant feed UDINT 1 4294967295 65536 1:1 X
179.9 Feed constant drive shaft
revolutions
UDINT 1 4294967295 1 1:1 X
179.10 Position actual value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.11 Position window UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
179.12 Target position DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.13 Home offset DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.14 Minimum software position
limit
DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.15 Maximum software position
limit
DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.16 Touch probe pos1 pos value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.17 Touch probe pos1 neg value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.18 Touch probe pos2 pos value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.19 Touch probe pos2 neg value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
179.20 Position error actual value DINT 0x80000000 0x7FFFFFFF 0 Inc 1:1 X
