INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 15-15
Chapter 15 Wheel Cleaning and CTA Options
Deluxe Wheel Stinger® with On-Board CTA Installation
5) Using the four 1/4-20 x 1” bolts with the appropriate washers and nuts, attach the Wheel
Stinger® Cover Support Mount Assembly to the onboard Manifold Mount located near the
bottom of the manifold.
6) If On-Board CTA is part of your system, locate the CTA Chamber Assembly and the On-
Board CTA Bracket. Secure them together using two of the 1/4-20 x 5/8” fasteners with
the appropriate washers and nuts as shown below.
