INSTALLATION AND STARTUP
15-18 Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 15 Wheel Cleaning and CTA Options
Deluxe Wheel Stinger® with On-Board CTA Installation
10) Run the 1/2” and 1/4” Poly-flow lines up into the central carriage of the FreeStyler® as
shown in example below.
Match and attach each line to its appropriate supplied 1/2” or 1/4” tee.
Note: The Tees should be installed in the middle of the central carriage so that there is an
even flow between the Primary and Secondary CTA applicators.
To Next Page
