Belanger FreeStyler - Chapter 2 Recommended Installation Sequence Checklist

INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681
Rev
Release
Date
Page
Description
14
L. Dietze
Prior to
9/7/21
1-3
Added IMPORTANT note and removed Before You Begin
1-4
Updated Danger Note and added reference to OSHA specifications
1-5
Added Warning note about Trained Electrician and Important note
1-7
Scope of this Manual was Greetings, Installation Manual was Owners Manual,
Ensure A Safe Work Environment was A Final Word on Safety (all sections updated
per current practices)
1-8
Added SAE Grade 8 torque value
1-9 to 1-12
Updated Component Idenification
2-1 to 2-2
Added Chapter references to Checklist. Removed Rocker Blaster from Item 10.d
3-1
Added Working Envelope: Overview, Utility Requirements moved to Chapter 5 –
Electrical
Changed height clearance from 131” to 133”
Changed page reference for Building Height Considerations from page 3-11 to page
3-14
3-2
Width Consideration section reformatted and added intro paragraph
3-3
Length Consideratins section reformatted
3-4 & 3-5
Changed titles to Square 4 Legged Frame:
Configuration #1 & #2 changed the dimension 130-1/2 and the note “The 130-1/2”
dimension taken from exit side edge of the leg“ to 124-1/2 and “The 124-1/2”
dimension is taken from entrance side edge of exit leg.”
Updated images using AutoCad Inventor assemblies.
Changed note: Positive Stop Clamps at Pre-Drilled Position to Position of the
Positive Stop Clamps will be determined by the bay length
3-6 & 3-7
Added pages to show Length Considerations for Oval 4 Legged Frame with optional
Freestanding Boom Mount. Updated images using AutoCad Inventor assemblies.
3-8
Length Considerations Involving Treadle Movement was Length Considerations and
the section was reformatted
3-9 & 3-10
Change titles to Square 6 Legged Frame:
Configuration 2 was Configuration 1 (both images), removed note to see next page
Updated images using AutoCad Inventor assemblies
Added “center leg” to the note explaining the 22-1/8 dimension
Changed note: Positive Stop Clamps at Pre-Drilled Position to Position of Positive
Stop Clamps will be determined by the bay length
3-11 & 3-12
Added pages to show Length Considerations for Oval 6 Legged Frame with optional
Freestanding Boom Mount. Updated images using AutoCad Inventor assemblies.
3-13
Length Considerations Involving Treadle Movement was Length Considerations and
the section was reformatted
3-14
Under Building Height Considerations, Ideal Height Scenario changed 131” to 133”
in two places
Changed both of the 131” dimensions in the image to 133”
3-15
Under Boom Mount Location added Freestanding Mount to Note.
3-16
Dimension P was D and dimension D was E
In sentence below charts changed “length considerations” to “width and length
consideration charts”
3-17
Under Equipment Locations removed the information for the Reservoir and Wall
Manifold.
3-17
Under Equipment Locations, Back Room Equipment removed the words “to the Wall
Manifold” from the following statement: Short runs from the Pumping Station and
Solution Delivery Modules to the Wall Manifold optimize performance.
Changed Injection Chemical System (ICS) to SDM Solution Delivery Pumps
3-17
In Establishing an Origin in the Bay removed Rocker Blasters/Roocker Spin Cleans.
3-17
System Control Center (SCC) Panel Layout moved to Chapter 5 – Electrical. Added
Skilled Trades, Equipment Locations and Establishing an Origin in the Bay
