Chapter 4 Frame and Carriage Assembly
Floor Mounted Frame
15) Slide the legs and corner clamps out to the end of the head beam or wall, whichever comes first,
and tighten the fasteners.
16) Measure the distance from the closest wall to the bottom of the leg on the entrance and exit side
of the machine
Set an equal distance on both ends.
Note: In a large building, the machine should be centered to the door if possible.
Note: In a small building, the legs can be set right up against the wall if necessary. The
corner clamps are located in their final position when the frame is in the air.
17) Using the supplied 5/8” lag bolts (1FSTNR-ST750), secure the frame to the floor at all 4 corners.
Note: If the rails are set at the 92-1/4’’ spacing, the rail is completely erected except the
rail travel stops.
Note: If the spacing is 100’’, the driver side head beam clamps should be loosened to where
the lock washers are not fully compressed, and the rail travel stops need to be
clamped on.
18) Verify that the Head Beams and rails at the center of each span is level to compensate for possible
sagging of the rails.
Determine the lowest corner that has the required 133” distance from the under-side of the
Head Beam to the floor.
19) Raise the other 3 corners to level the Head Beams and rails.
Note: Leveling is CRITICAL for proper machine operation!
Note: After this point, the forklifts are no longer necessary and leveling also becomes far
more difficult without the forklifts.
