INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 4-11
Chapter 4 Frame and Carriage Assembly
Carriage Prep
Adjusting the Rails
2) Replace the 5 roller nuts to secure the roller into position.
Note: The carriage is now prepared for placement onto the rails.
3) Once the carriage is positioned onto rails correctly, replace the roller cap.
Note: It may be necessary to use the Jack Bolt to safely reinstall the wheel caps.
