Belanger FreeStyler - Page 8

INSTALLATION AND STARTUP
Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Rev
Release
Date
Page
Description
17-2
Relocated Frame Installation and Installing the Boom Mount sections from Chapter
4 (Frame and Carriage) in rev 13.
Re-wrote the last two sentences in Overview: Frame Installation was: The only
addition will be an additional head beam and center mount leg. These items are
centered on the rails and installed in the carriage and centered on the rails. See
page 17-2 for the changed version.
Changed dimension in image from 23-1/16” to 22-1/8”
Added Frame to note in image
Add “or Freestanding” to note in image
Chap 18
New Chapter added to manual - Spot Free Rinse (R.O.) Option, existing information
was in Chapter 9 of Rev 13, new information updated to current practices
Chap 19
New Chapter added to manual - Trades per current practices
Chap 20
New Chapter added to manual - Electrical per current practices
Chap 21
New Chapter added to manual – Pneumatic and Hydraulic Connections
Chap 22
Was Chapter 10 in rev 13
22-4
Updated MCC Startup per current practices
22-5 to 22-6
SCC and Other Components was SCC. Section updated per current practices.
22-7 to 22-9
Check Inputs and Motion was SCC. Section updated per current practices.
22-10 to 22-
11
De-Stroking Cylinder Arms was Entrance Arm Cylinders, Exit Arm Cylinders. Added
instruction for Entrance Arm Cylinder. Updated image in Exit Arm Cylinder.
22-13
Added “Clear FORCED ovals” step in Top Wheel instruction
22-16
Added Installing the Triple Foam Pods
22-20
Added Nozzle part numbers and Tip information
22-21
Added images
22-24 to 22-
25
Running Test Vehicles was Vehicle Testing. Section was reorganized and added
Equalizing the Entrance or Exit Wheel Penetration section title.
14
Randy
Morton
9/7/21
3-14, 4-1, 4-
7, 4-10 & 4-
14
Added the following Note: The forklift considerations for the carriage are as follows:
load weight of the carriage is 2,250 lbs., load is 136” wide, load center is 40”, and the
load needs to be lifted 72” high.
4-49 and
4-50
Added anti-seize not in the note box (felt like it needed more attention brought to it)
8-7
Changed VCT-HPW-001 to 106999
12-4
Removed image showing placement of Pump below Injector it did not accurately
support note, Note is sufficient.
14-16
Changed NZZL-105982 to NZZL-105980
14-17
Changed 1NOZZL-HP125 to 1NOZZL-MG200
Changed TIP: MEG2025 to MEG0505
14-18
Changed 1NOZZL-HP120 to 1NOZZL-MG100
Changed TIP: MEG2025 to MEG0502
20-2
Added Hydro Blade Water GPM and PSI to Chart for the 10HP & 25 HP Pump
Stations
20-6
Corrected the word “Topwheel”
22-8
In text box, specified the Prox Gaps as 1/4" per Engineering
22-20
Changed 1NOZZL-FJ154 to 1NOZZL-FJ254 for the Exit Wheels Lower Nozzle
