INSTALLATION AND STARTUP
4-30 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 4 Frame and Carriage Assembly
Passenger Side Boom Install
Optional HydroBlade®/ Wheel Cleaner
Wheel Cleaner Center Feed Manifolds
1) Remove the clamps that are circled below to remove the manifold assembly (as shown below).
2) Change the orientation of the components pointed out below.
3) Secure the manifold assembly into place and re-connect the hoses to the previous fitting locations. See image
below.
