Parameter descriptions
With the parameters Analog: Voltage 100% 551 and Analog: Voltage 0%552, the voltage range at
100% and 0% of the output parameter is set. If the output value exceeds the reference value, the
output voltage also exceeds the value of the parameter
Analog: Voltage 100%551 up to the maxi-
mum value of 22 V (or the maximum value of an external voltage supply).
If Operation Mode MFO1 (X13.6) 550 = Analog (PWM) MFO1A and parameter s Ana-
log: Voltage 100% 551 < Analog: Voltage 0% 552, then the smaller voltage value of
Analog: Voltage 100% 551 is put out.
553 Analog: Source MFO1A
If the multifunction output is to be used as analog output, parameter
Operation Mode MFO1
(X13.6)
550 must be set to "10 - Analog (PWM) MFO1A".
For parameter
Analog: Source MFO1A 553, the analog actual value to be output at the multifunction
output can be selected.
Operation mode MFO1
(X13.6) 550
7 - Abs. Actual Frequency
Select an analog signal source.
Analog mode at the multifunction output is switched off.
1 -
Abs. Fs
Abs. value of the stator frequency. 0.00 Hz ... Maximum Fre-
quency 419.
2 -
Abs. Fs betw. fmin/fmax
Abs. value of the stator frequency. Minimum Frequency 418...
Maximum Frequency 419.
7 -
Abs. Actual Frequency
Abs. value of act. frequency. 0.00 Hz ... Maximum Frequency
419. Factory setting.
10 -
Abs. Reference Percentage
Absolute value of reference value from reference percentage
channel. Total of Reference Percentage Source 1 476 and Refer-
ence Percentage Source 2 494.
11 -
Abs. Ref. Percentage betw.
%min/%max
Absolute value of reference value from reference percentage
channel. Minimum Reference Percentage 518 … Maximum Ref-
erence Percentage
519. Total of Reference Percentage Source
1 476 and Reference Percentage Source 2 494.
20 -
Abs. Iactive
Abs. value of current effective current I
Active
. 0.0 A ... Nominal
frequency inverter current.
21 -
Abs. Isd
Abs. value of flux-forming current component. 0.0 A ... Nominal
frequency inverter current.
22 -
Abs. Isq
Abs. value of torque-forming current component. 0.0 A ... Nomi-
nal frequency inverter current.
30 -
Abs. Pactive
Abs. value of current effective power P
Active
. 0.0 kW ... Rated
Mech. Power 376.
Abs. value of calculated torque M, 0.0 Nm ... rated torque.
Abs. value of measured inside temperature. -20 °C ... 100 °C.
33 -
Abs. Heat Sink Tempera-
ture
Abs. value of measured heat sink temperature. -20 °C ... 100 °C.
Abs. Capacitor temperature
Abs. value of measured capacitor temperature. -20 °C ... 100 °C.
Abs. signal value at analog input MFI1A. DC 0.0 V ... 10.0 V.
Abs. signal value at analog input MFI2A. DC 0.0 V ... 10.0 V.
50 -
Abs. I
Abs. current value of measured output currents. 0.0 A ... Nominal
frequency inverter current.
DC-link voltage U
d
. DC 0.0 V ... 1000.0 V.
Output voltage. 3xAC 0.0 V ... 1000.0 V.
183
Control inputs and outputs 06/2013 Operating Instructions
