Parameter descriptions
Analog: Source MFO1A 553
Function
61 -
Abs. Val. PLC-Output Per-
centage 1
Output value "2521 – PLC Output Percentage 1" of a PLC-
function is output via the multifunction output. Refer to applica-
tion manual "PLC".
62 -
Abs. Val. PLC-Output Per-
centage 2
Output value "2522 – PLC Output Percentage 2" of a PLC-
function is output via the multifunction output. Refer to applica-
tion manual "PLC".
101 to 162 Operation modes in analog operation with signs.
By default, the multifunction output is configured for the output of a pulse width modulated output
signal with a reference voltage value of DC 10 V.
554 Digital: Source MFO1D
If the multifunction output is to be used as a digital output, parameter
Operation Mode MFO1
(X13.6)
550 must be set to "1 - Digital MFO1D".
For parameter
Digital: Source MFO1D 554, the signal to be output at the multifunction output can
be selected.
Parameters
Factory setting
Set
Operation mode MFO1
(X13.6) 550
10 - Analog (PWM) MFO1A
1 - Digital MFO1D
Digital: Source MFO1D 554
4 - Setting frequency
(Refer to 7.6.5.2 "Setting
frequency".)
Select a digital signal source.
(Refer to 7.6.5 “Digital outputs”,
table “Operation modes for digital
outputs”.)
555 RF/PT: Output Value MFO1F(repetition frequency/pulse train)
Multifunction output MFO1 can be used as a frequency output. Parameter
Operation Mode MFO1
(X13.6)
550 must be set to "20 - Repetition Frequency (RF) MFO1F". The output signal can be select-
ed via parameter
RF/PT: Output Value MFO1F 555.
Parameters
Factory setting
Set
Operation mode
MFO1 (X13.6) 550
10 - Analog (PWM) MFO1A
20 - Repetition Frequency (RF) MFO1F
RF/PT: Output Value MFO1F 555
Function
0 - Off Repetition frequency mode switched off.
1 - Actual Frequency
Abs. value of the Actual frequency 241.
Factory setting.
2 -
Stator Frequency
Abs. value of the Stator frequency 210.
5 -
Repetition Frequency Input
Abs. value of the Repetition frequency input 252.
The maximum frequency value output is:
)()(2f
max outp.
556419
marks Division :FFrequencyMaximum
R××=
Scaling
If the multifunction output is set as a frequency output, the output frequency can be scaled. Parame-
ter
Operation Mode MFO1 (X13.6) 550 must be set to "20 - Repetition frequency (RF) MFO1F".
556 RF: Division marks (repetition frequency mode)
The repetition frequency mode for the multifunction output corresponds to the emulation of an incre-
mental sensor. The parameter
RF: Division marks 556 must be parameterized according to the fre-
quency to be output.
184
Operating Instructions
Agile 06/2013 Control inputs and outputs
