BONFIGLIOLI Agile User Manual

Parameter descriptions
Parameters
Setting
No.
Description
Min.
Max.
Fact. sett.
556
RF: Division marks
30
8192
1024
The frequency limit of f
max
= 150 kHz may not be exceeded in the calculation of the parameter RF:
Division marks
556.
valuefrequency Reference
Hz 150000
S
max
=
Pulse train output
A pulse train signal (pulse sequence) can be output as a master frequency.
If the multifunction output is to be used as a pulse train output, parameter
Operation Mode MFO1
(X13.6)
550 must be set to "30 - Pulse Train (PT) MFO1F".
Parameters
Factory setting
Set
Operation mode MFO1
(X13.6)
550
10 - Analog (PWM) MFO1A
30 - Pulse Train (PT) MFO1F
557 PT: Scaling Frequency (pulse train)
Parameter
PT: Scaling Frequency 557 indicates which frequency the multifunction output outputs at
100% maximum frequency. Thus, the scaling also depends on the setting of parameter
Maximum
frequency
419.
Parameters
Setting
No.
Description
Min.
Max.
Fact. sett.
557 PT: Scaling Frequency 0 32000 25000
If parameter
PT: Scaling Frequency 557 is set to zero, the frequency value at the multifunction out-
put will not be scaled.
The output value is limited to the value 2 x
Maximum Frequency 419.
Example: Reference value 50 Hz, Maximum Frequency 419 = 100 Hz
PT: Scaling Frequency
557
Output frequency [Hz]
0 50
1 0.5
10 5
100
50
1000
500
Example: Reference value 25 Hz, Maximum Frequency 419 = 50 Hz
PT: Scaling Frequency 557
Output frequency [Hz]
0 25
1000
500
185
Control inputs and outputs 06/2013 Operating Instructions
Agile
