BONFIGLIOLI Agile User Manual

Parameter descriptions
Control signals
Function
Selection for parameter
170 - Warning Overtemperature
The value
− (Maximum heat sink temperature T
K
) minus (Warning Limit
Heat Sink Temp.
407) or
− (Maximum inside temperature T
i
) minus (Warning Limit In-
side Temp.
408)
was reached.
175 - Digital Signal OUT1D
Signal selected via
Op. Mode OUT1D (X13.5)
531.
176 - Digital Signal OUT2D Relay
Signal selected via
Op. Mode OUT2D (X10/Relay)
532.
177 - Digital Signal OUT3D
Signal selected via
Op. Mode OUT3D (X11.6)
533.
178 -
Reference Percentage
reached
Signal when the Actual Percentage Value 230 has reached the
Reference Percentage Value
229.
179 - Mains Failure
Failure of the mains voltage and power regulation active accord-
ing to Operation Mode 670 for the voltage controller.
180 -
Warning Motor Protection
Switch
Parameterized Operation Mode 571 of the motor circuit breaker
triggered.
181 - Digital Signal MFO1D
Signal selected via
Digital: Source MFO1D 554
.
215 - Warning Mask, Application
The defined warning mask of parameter Create Appl. Warning
Mask 626 signals a critical operating point.
216 - Application Warning
All Application Warnings are deactivated. Display is effected via
parameter Application Warnings 273.
219 -
Technology Controller
within Backlash
The control deviation lies within the range defined by Back-
lash 618.
264 - Warning service DC-link
Signal if the time remaining until service has expired. Parameter
Operation Mode Service Interval DC-link 1534 must be set to
“2 - Alarm Message”. Parameter
Maintenance Note 1533 dis-
plays a message.
265 - Warning service fan
Signal if the time remaining until service has expired. Parameter
Operation Mode Service Interval Fan 1535 must be set to “2 -
Alarm Message”. Parameter
Maintenance Note 1533 displays a
message.
270 to 277
Operation modes 70 to 77 of the digital inputs inverted (LOW
active).
284 - STOA inverted Inverted signal status on digital input STOA for enable.
285 - STOB inverted Inverted signal status on digital input STOB for enable.
292 - STOA Signal status on digital input STOA for enable.
293 -
STOB
Signal status on digital input STOB for enable.
323 - Power is on
Signal if mains voltage is switched on and pre-charging is fin-
ished.
471 -
Energy saving function is
active
Parameter Operation mode energy saving function 1550 is set
to “1 - manual” or “2 - automatic”. The digital input or logic sig-
nal selected for parameter
Energy saving function on 1552 has
switched on the energy saving function.
198
Operating Instructions
Agile 06/2013 Control inputs and outputs
