60/188 Installation
Bosch Rexroth AG, MIT: ActiveMover, 3 842 564 874/2021-04
Fig. 36:
600,00
199,75
557 186-35
9
9
SW5
4x
M
D
=16 Nm
SW5
4x
M
D
=16 Nm
4,5 mm
4,5 mm
4,5 mm
199,75
3842559429
3842559429
Assembling the module holder on the section module (2)
9. Assemble and align
the module holders
3 842 559 429.
