4-6
Confidential
(3) Remove the Bush of the Back cover from the Shaft at the right side of the Main body.
Fig. 4-3
(4) Remove the Back cover from the Shaft at the left of the Main body.
Fig. 4-4
Main body
Back cover
Bush
Bush
Shaft
Shaft
<Right side>
3a
3b
3c
<Back side>
Main body
Shaft
Back cover
<Left side>
