5-70
Confidential
(5) Remove the ADF sensor PCB ASSY from the Lower document chute ASSY.
(6) Remove the ADF sensor harness ASSY from the ADF sensor PCB ASSY.
Fig. 5-56
Harness routing: Refer to “ ADF Unit.”
ADF sensor PCB ASSY
ADF sensor harness ASSY
5a
5b
Lower document chute ASSY
6
