5-93
Confidential
(8) Disconnect the Connector of the WLAN-MAIN harness ASSY from the Wireless LAN PCB
ASSY.
Fig. 5-93
Harness routing: Refer to “ Front Cover Top ASSY (Wireless LAN PCB ASSY, Speaker
Unit).”
Wireless LAN PCB ASSY
WLAN-MAIN harness ASSY
