5-194
Confidential
Fig. 5-254
Assembling Note:
When assembling the HVPS insulation sheet 1 and HVPS insulation sheet 2, make sure to
assemble them as sandwiching the Flat cable of the High-voltage power supply PCB ASSY
with them.
HVPS insulation sheet 2
HVPS insulation sheet 1
High-voltage power supply
Flat cable PCB ASSY
