5-193
Confidential
(6) Remove the HVPS insulation sheet 2 from the High-voltage power supply PCB ASSY.
Fig. 5-252
(7) Remove the HVPS insulation sheet 1 from the High-voltage power supply PCB ASSY.
Fig. 5-253
High-voltage power supply PCB ASSY
HVPS insulation sheet 2
High-voltage power supply PCB ASSY
HVPS insulation sheet 1
7b
7a
