5-202
Confidential
(4) Remove the two Electrode head 2 and two Belt cleaner spring from the Side frame R.
Fig. 5-269
(5) Remove the two Belt cleaner springs from the two Electrode head 2.
Fig. 5-270
Side frame R
Electrode head 2
Belt cleaner spring 3
Electrode head 2
Belt cleaner spring
