7-19

Confidential

Fig. 7-11

Fig. 7-12

Document front sensor

Document rear sensor

ADF cover open sensor

ADF unit

Document scanner unit

ADF sensor

PCB ASSY

Scanner top cover

FB unit home

position sensor
