App.1-6
Confidential
â– WSW03 (PABX mode setting)
* PABX: Private automatic branch exchange
- Selectors 1 and 5: CNG detection when sharing a modular wall socket with a telephone
These selectors determine whether or not the machine detects a CNG signal when a line is
connected to a telephone sharing a modular wall socket with the machine. Upon detection of CNG
signals by the number of cycles specified by these selectors, the machine interprets CNG as an
effective signal and then starts FAX reception.
Selector No. Function Setting and Specifications
1
CNG detection when sharing a
modular wall socket with a telephone
0: A
1: B
2
|
4
Detection time length of PABX* dial
tone, required for starting dialing
(Not used.)
5
CNG detection when sharing a
modular wall socket with a telephone
0: A
1: B
6
7
Dial tone detection in PABX*
(Not used.)
8 Not used.
Note:
Selectors 2 through 4, 6 and 7 are not applicable where no PABX is installed.
Selector
Cycle
No. 1 No. 5
0 (A) 0 (A) 0.5 cycle
0 (A) 1 (B) 1.0 cycle
1 (A) 0 (A) 1.5 cycle
1 (B) 1 (B) 2.0 cycle
